Hopper Shaped Progressing Cavity Pump

Hopper Shaped Progressing Cavity Pump
Hopper Shaped Progressing Cavity Pump
Send Inquiry
Product Code : NEMO-BO_BS
Brand Name : NETZSCH
Price And Quantity
  • Minimum Order Quantity
  • 1 Kit
  • Price Range
  • 50000.00 - 500000.00 INR/Kit
  • Price
  • 50,000 to 5,00,000 INR/Kit
Product Specifications
  • Color
  • NETZSCH Green
  • Product Type
  • Positive Displacement Pumps
  • Theory
  • Other
  • Head Size
  • 72 Bar
  • Flow Rate
  • Up to 200 M3/hr
  • Material
  • CI/SS
  • Structure
  • Screw Pump
  • Power
  • Electric
  • Fuel Type
  • Other
  • Pressure
  • High Pressure
  • Usage
  • Other
  • Application
  • Other
  • Seals Type
  • Gland Packing / Mechanical Seal
Product Description

Product Description

Brand
NETZSCH
Condition
New
Head
Up to 72 Bar
Max Flow Rate
Up to 200 M3/hr
Model
NEMO
Product Type
Positive Displacement Pumps

NEMO® Hopper Shaped Progressing Cavity Pump design can be used in any area of industry where a great variety of different substances must be pumped or very precisely dosed.

The Hopper Shaped Progressing Cavity Pump with square/rectangular hopper and coupling rod with feeding screw and force-feed chamber is employed in almost all branches of industry to provide continuous, pressure-stable, gentle and low-pulsation conveyance.

Features:

  • Minimal noise level
  • Low energy consumption
  • High resistance to abrasion and corrosion
  • Ability to pump wide range of fluid viscosities
  • Simple installation, operation and maintenance
  • Product remains unchanged during pumping process
  • Simple operation as the single helical rotor rotates inside the double helical, elastomer-lined stator
  • The rotor rotates eccentrically in the stator through a series of sealed cavities for 180 degrees therefore progressing the medium from the intake to the discharge end of the assembly
  • The volumetric efficiency is directly proportional to the number of rotations of the pump to the size of the cavity formed between the rotor and stator
  • Another captivity is created after one is diminished at the same rate resulting in a constant non-pulsating flow

Well-suited for the following substances:

  • Slowly flowing and non-free-flowing substances
  • Substances with solid content
  • Shear-sensitive
  • Smearing or non-smearing
  • Thixotropic and dilatant
  • Abrasive

Applications:

  • Thickened or concentrated sludge, viscous pastes, cod-liver oil, fish spawn, sausage paste, lard, dough, potato pulp, etc.

Item code: NEMO-BO_BS
